GM400 1U Bronze
Cybenetics Bronze 400W 1U redundant power supply
- 400+400W 24 hours and well-working performance at 45℃ fully continuous power output
- 1U redundant form factor with 106mm(W) x 41.5mm(H) x 260mm(D)
- 1+1 redundant configuration
- Hot swappable design
- Convenient pull-out handle bars
- Industry-leading reliability
Designed for Cybenetics Bronze level of efficiency to reduce wasted heat and save on electricity
Powerful single +12V rail design, perfect for future high-end component upgrades or overclocking
Convenient pull-out handle bars
400+400W continuous power output at 45°C operating temperature rated for 24/7 operation
1U redundant form factor with 106mm(W) x 41.5mm(H) x 260mm(D)
Advanced protections for safety and security
Over current protection
Over voltage protection
Short circuit protection
Under voltage protection
Product Specifications
Product No.
SST-GM400-1UB
Model (safety certification)
SST-1R0400FCBR-A
Color
Silver
Max. DC Output
400W
Power density
699W per liter
Load Range
| Output | +3.3V | +5V | +12V | +5VSB | -12V |
|---|---|---|---|---|---|
| Max.(Amps) | 20A | 20A | 32A | 3.0A | 0.5A |
| Min.(Amps) | 1.0A | 1.0A | 1.0A | 0.5A | 0A |
| Range (%) | ±5% | ±5% | ±5% | ±5% | ±10% |
| Line Reg.(%) | ±1% | ±1% | ±1% | ±1% | ±1% |
| Ripple(mVp-p) | 60mV | 60mV | 120mV | 50mV | 120mV |
Combined +3.3V & +5V
150W
Combined +12V
384W
Input Voltage
90 ~ 264 Vrms
Input Frequency Range
47Hz ~ 63Hz
PFC
Active PFC (PF>0.9 at full load)
Efficiency
≥82% & <85% overall efficiency with single modular power supply
MTBF
100,000 hours
Operating temperature
0°C ~ 45°C
Protection
Over current protection
Over voltage protection
Under voltage protection
Short circuit protection
Over voltage protection
Under voltage protection
Short circuit protection
Connectors
1 x 24 / 20-Pin motherboard connector
1 x 4-Pin EPS / ATX 12V connector
1 x 8-Pin EPS / ATX 12V connector
3 x SATA connectors
5 x 4-Pin Peripheral connectors
1 x 4-Pin Floppy connector
1 x 2-Pin +5V TTL signal connector
1 x Brown / white power 1 LED
1 x Red / white power 2 LED
1 x Green / white power / modular system LED
1 x 4-Pin EPS / ATX 12V connector
1 x 8-Pin EPS / ATX 12V connector
3 x SATA connectors
5 x 4-Pin Peripheral connectors
1 x 4-Pin Floppy connector
1 x 2-Pin +5V TTL signal connector
1 x Brown / white power 1 LED
1 x Red / white power 2 LED
1 x Green / white power / modular system LED
Cooling System
40mm DC fans
Noise Level
52 dBA
LED indicator
| Power Supply Condition | Power System Status | Module Status |
|---|---|---|
| No AC power to all PSU | OFF | OFF | OFF |
| AC present / only standby output on | RED | OFF | OFF |
| Power supply DC output ON and OK | OFF | GREEN | ORANGE |
| Power supply failure | OFF | GREEN Blinking | OFF |
Certification
Cybenetics Bronze
Form factor
1+1 1U redundant
Dimension
123mm (W) x 41.5mm (H) x 270mm (D)
4.84" (W) x 1.63" (H) x 10.63" (Housing with bracket, without handle)
106mm (W) x 41.5mm (H) x 260mm (D)
4.17" (W) x 1.63" (H) x 10.24" (D) (Housing without bracket)
50mm (W) x 40mm (H) x 220mm (D)
1.97" (W) x 1.57" (H) x 8.66" (Module only without handle)
4.84" (W) x 1.63" (H) x 10.63" (Housing with bracket, without handle)
106mm (W) x 41.5mm (H) x 260mm (D)
4.17" (W) x 1.63" (H) x 10.24" (D) (Housing without bracket)
50mm (W) x 40mm (H) x 220mm (D)
1.97" (W) x 1.57" (H) x 8.66" (Module only without handle)
Weight
2.15 kg
Other
● Specifications presented on this page contains most recent revisions and may differ from those printed on retail boxes or manuals.
